DuroSpan® GPS R5 Insulation
DuroSpan® GPS R5 Insulation Board is a higher R-value product with an R-value of 4.7 per inch manufactured with NEOPOR – a graphite enhanced polystyrene. GPS is a closed cell insulation with a silver-gray colour that meets or exceeds requirements for expanded polystyrene (EPS) manufactured to CAN ULC S701.1.
DuroSpan GPS R5 is manufactured to meet code requirements, with a thin film laminated to both sides for a more durable, flexible product. This easy to cut and install insulation has Low GWP, maintain a permanent R-value for the life of the product, and is part of an air barrier system. DuroSpan GPS R5 demonstrates code compliance for Intertek CCRR-1033.
DuroSpan GPS R5 is an excellent choice for insulating applications with low water absorption properties, and has a compressive resistance of 10 psi. Markings provided on the printed face of DuroSpan GPS R5 insulation assist in cutting to required dimensions and spacing of fasteners into framing.
Available in: 4x8, 4x9 and 4x10 feet sizes, 2 feet high bundles
DuroSpan GPS is manufactured in thicknesses of 1-1/16 – R5, 1-5/8 – R7.5, and 2-1/8 – R10, as well as other R-values available upon request.
- Enhanced thermal resistance & permanent R-value
- Reduces heat loss
- Improved Interior temperatures
- Durable product less susceptible to handling damage
- Easy to cut and install
- Meets CAN ULC S701.1-Type 1
- Intertek CCRR-1033
CAN/ULC-S701.1 Material Properties of DuroSpan® GPS R5 Insulation
| Material Property | Test Method | Units | Type 1 |
|---|---|---|---|
|
Thermal Resistance Minimum RSI per 25mm (R per inch) |
ASTM C518 |
m2 • 0C/W (ft2•h•0F/BTU) |
0.82 (4.7) |
|
Compressive Resistance Minimum @ 10% Deformation |
ASTM D1621 |
kPa (psi) |
70 (10) |
|
Flexural Strength Minimum |
ASTM C203 |
kPa (psi) |
170 (25) |
|
Water Vapour Permeance Maximum |
ASTM E96 |
ng/(Pa.s.m2) (Perms) |
30 (0.5) |
|
Water Absorption Maximum |
ASTM D2842 |
% By Volume | 6.0 |
|
Dimensional Stability Minimum |
ASTM D2126 |
% Linear Change | 1.5 |
|
Limiting Oxygen Index Minimum |
ASTM D2863 |
% | 24 |
| Standard Products | |||
|---|---|---|---|
| Width, mm (in) | Length, mm (ft) | RSI - m2•oC/W | R-value - ft2•hr•oF/BTU |
| 1,222 (4) | 2,444, 2,743 or 3,658 (8, 9 or 10) | 0.88, 1.32, 1.76 | 5.0, 7.5 or 10.0 |
